Transport - Industries

AV600-RH Military IP66 AI Edge GPU Computer

Military IP66 with D38999 connectors VIDIA RTX A1000/A2000, 2048/2560 CUDA

Key Features:

MIL-STD 810 Thermal, shock, vibration, Humidity / EMI / EMC conditions
IP66 Chassis with D38999 connectors
Intel 13th Gen. Raptor Lake (H) i7-13800HE/HRE, 14C , 2.5/5.0 GHz Processor
Up to 64GB DDR5 SO-DIMM, non-ECC and ECC
NVIDIA RTX A1000/A2000, 2048/2560 CUDA,4GB/8GB GDDR6 RAM
MIL-STD-461 EMI Filter18V~36V DC-Input
Extreme Temperature : -40°C to 60°C
Dimensions : 250(L) x 325 (W) x 100 (H) mm

View Product

ATC3540 NVIDIA Jetson Orin NXEdge AI Computer

NVIDIA Jetson Orin NX Solution Accelerated Edge AI Computing

Key Features:

Edge AI in-vehicle/rail computer
Built-in NVIDIA® Jetson Orin™ NX SOM, up to 100 INT8 TOPS compute
4-port GbE PoE+ for IP CAM/LiDAR sensors
HEVC/H.265 hardware CODEC, 18 x 1080p30 compute power (decoded)
Wide range operating temperature of -30~70°C
The rugged, fanless design with an IP67 rating
Ultra-speed PCIe 4.0 x4 NVMe SSD for data integrity
NEXCOM Acceleration Linux (NAL) OS w/ JetPack 5.1.1 integrated
Expansible for LTE/5G NR & Wi-Fi 5/6
9~36V DC-in with ignition control & OCP/OVP
CE/FCC, UKCA, Emark/EN50155 certified

View Product

LPM2-7-27[-X] Ultra Low Profile MiMo IOT Antenna

Panorama LPM2-7-27[-X] Ultra Low Profile MiMo IOT Antenna IP69K 4G/LTE 2x2 MiMo

Key Features:

Offers ultra-low-profile MiMo 4G/LTE coverage.
Weatherproof housing contains two antenna elements with effective isolation.
Designed for panel mounting, it provides plug-and-play connectivity with various routers and modems.
Integrated flame retardant RG174 cables and SMA plug connectors.
Supplied in black flame retardant LEXAN EXL9330 plastic as standard.

View Product

L[G]M[X]M[X]-6-60[-24-58] MiMo 4G/5G Dome Combination Antenna

Panorama L[G]M[X]M[X]-6-60[-24-58] MiMo 4G/5G WiFi Dome Combination Antenna Range IP69K 6x6 MiMo

Key Features:

Provides 2x2 4G/5G MiMo performance from 617-960/1710-6000MHz.
Flexible platform allows integration with GPS/GNSS and up to 6x6 MiMo WiFi (2.4/4.9-7.2GHz).
Antenna is panel mounted and suitable for both conductive and non-conductive panels.
LGM variants include integrated GPS/GNSS module with advanced filtering for LTE B13/14 interference.
Available with black or white radome, meeting IK10 for vandal resistance and IP69K for ingress protection.

View Product

TRNM[X]4-6-60-[X] 4X4 MiMo 4G/5G Transport Antenna

4x4 MiMo 617MHz to 6000MHz 4G/5G EN50155, EN45545-2 (HL 1-3), EN50124-1, IP69K

Key Features:

Low Profile Transit Antenna
4x4 MiMo 617-960/1427-6000MHz
Up to 4x4 MiMo WiFi 6e
Covers global 4G/5G frequencies
Optional active GPS/GNSS

View Product

VTC7270-C8 GEN 12/13 Fanless 8 x POE AI Vehicle Computer

12/13th Gen Intel Core CPU 8 x 2.5GbE PoE+, 1 x GbE, 6 x USB 3.2, 4 x Serial, 2 x 2.5” SSD, 2 x CAN FD, 9~36VDC/IGN

Key Features:

Powered by 12/13th Gen Intel® Core™ i with DDR5, excellent memory bandwidth, lower latency
Rich I/Os, 8 x 2.5GbE PoE+, 1 x GbE, 6 x USB 3.2, 2 x CAN FD & 4 x Serials
Up to 4 WWAN/WLAN combinations for mobile router Applications
2 x 2.5” SSD, 1 x NVMe ultra-speed SSD for data integrity
Up to two Hailo AI accelerators (26TOPS workload each) in option
9~36V DC-IN with ignition control & OCP/OVP
Wide range operating temperature of -40°C~65°C (fanless@35W CPU)
Military standard for anti-vibration/shock
CE/FCC, UKCA, Emark Certified

View Product

GPSD-7-27 MiMo 'Sharkee™' 4G GPS/GNSS Whip Mounting MiMo WiFi

Panorama GPSD-7-27 Low Profile MiMo Antenna Wi-Fi GNSS 4G/5G

Key Features:

OEM shark fin styling
GPS/GNSS, MiMo 4G/3G/2G & Optional MiMo 2.4/4.9-6GHz
Support for VHF or UHF external antenna

View Product

L[G]P-7-38[-24-58] Low Profile Multifunction Puck Antenna 4G WiFi GPS/GNSS

Panorama L[G]P-7-38[-24-58] Low Profile Puck Antenna Wi-Fi GNSS 4G/5G

Key Features:

Low Profile ‘Hockey Puck’ Design
3G/4G+ Optional WiFi & GPS/GNSS Functionality
Suitable for M2M and IOT Installations

View Product

LP[G]E-6-60[-X] 'The Fez' Low Profile Antenna 4G/5G WiFi GPS

Panorama LP[G]E-6-60[-X] Low Profile 4G/5G WiFi GPS 4x4 MiMo Antenna

Key Features:

Rugged Low Profile Design
Wideband 4G/5G Element
Optional up to 4x4 MiMo Dual Band WiFi + 6e
Optional Integrated GPS/GNSS Antenna

View Product

LP[G]-7-38[-24-58] Low Profile loT Antenna 3G-5G GPS WiFi IP69K

Panorama LP[G]-7-38[-24-58] Low-profile antenna 5G 30dB LNA FAKRA/SMA IK10 IP69K

Key Features:

Low Profile - Ground Plane Independent
3G/4G/5G - Optional GPS/GNSS & WiFiw
Ideal for M2M and loT Applications
Meets IK10 and IP69K

View Product

EPD-2501 Public Information e-Ink Display

Onboard Intel Celeron SoC BGA Processor N3350

Key Features:

25.3” E Ink Black/White/Red/Yellow
25.3” E Ink Gallery Plus Full colour 55K (Typ.)
25.3" E Ink Kaleido with colour 4096
Onboard Intel® Celeron® SoC BGA Processor N3350
DDR3L 1866MTs SO-DIMM up to 8GB,
2.5” SATA3 SSD 64GB
2 x HDMI, 1 x COM, 2 x LAN, 4 x USB 3.1(Gen1)
Front Cover Glass, Optional PMMA, support IP54
Super Slim Bezel Design
E Ink SDK / API support
Optional WiFi Module
Operating Temp 0~40C

View Product

ATC3750-A6CR NVIDIA Jetson AGX Orin Edge AI Computer

NVIDIA Jetson AGX Orin Solution Performance Edge AI Computing for Rail

Key Features:

Built-in NVIDIA® Jetson AGX Orin™ SOM, up to 200/275 TOPS (INT8) performance
Designed with rugged, compact and hybrid cooling solutions
6-port GbE PoE+ (X-coded) for IP CAM/LiDAR sensors, optional 1-port 10GbE (X-coded)
HEVC/H.265 hardware DECODE up to 7 x 4K30 performance
Wide range operating temperature of -20°C~70°C
Ultra-speed PCIe 4.0 x4 NVMe SSD for data integrity
Expansible for GNSS, LTE/5G NR & Wi-Fi 5/6
24V DC-IN for rail, ignition control & OCP/OVP
NEXCOM Acceleration Linux (NAL) integrated w/ JetPack 5.0.2
Military standard of MIL-STD-810H for anti-vibration/shock
CE/FCC, UKCA, EN50155 (EN55011, EN50121-3-2, EN61373, OT4) Certified

View Product

IPC960A Fanless Industrial System 12th Gen

LGA1700 Socket 12th Gen Intel Core i7/i5/i3 or Celeron Processor, Intel H610E/Q670E, and Front-access I/O

Key Features:

Fanless embedded system
Optional extension system I/O window
Optional 5G network (Q670E)
USB power on/off control via BIOS setting
Intelligent power management - ACC ignition
EN 61000-6-2 certified
Supports Intel RST

View Product

IPC964A Four-slot Industrial System 12th Gen

LGA1700 Socket 12th Gen Intel Core i7/i5/i3 or Celeron Processor, Intel Q670E, Front-access I/O, and PCIe & PCI Slots

Key Features:

4 PCIe/PCI slots
Optional extension system I/O window
Optional Support 5G network (Q670E)
USB power on/off control via BIOS setting
Intelligent power management - ACC ignition
EN 61000-6-2 certified
Supports Intel RST

View Product

VTC7270-C4 GEN 12/13 Fanless 4 x POE AI Vehicle Computer

12/13th Gen Intel Core CPU 4 x 2.5GbE PoE+, 1 x GbE, 6 x USB 3.2, 4 x Serial, 2 x 2.5” SSD, 2 x CAN FD, 9~36VDC/IGN

Key Features:

Powered by 12/13th Gen Intel® Core™ i with DDR5, excellent memory bandwidth, lower latency
Rich I/Os, 4 x 2.5GbE PoE+, 1 x GbE, 6 x USB 3.2, 2 x CAN FD & 4 x Serials
Up to 4 WWAN/WLAN combinations for mobile router Applications
2 x 2.5” SSD, 1 x NVMe ultra-speed SSD for data integrity
Up to two Hailo AI accelerators (26TOPS workload each) in option
9~36V DC-IN with ignition control & OCP/OVP
Wide range operating temperature of -40°C~65°C (fanless@35W CPU)
Military standard for anti-vibration/shock
CE/FCC, UKCA, Emark Certified

View Product

VTC7270 Fanless AI Powered Vehicle Computer

12/13th Gen Intel Core CPU 2 x 2.5GbE, 1 x GbE, 6 x USB 3.2, 2 x CAN FD & 4 x Serials, extra 4 x 2.5GbE PoE

Key Features:

Powered by 12/13th Gen Intel® Core™ i with DDR5, excellent memory bandwidth, lower latency
Rich I/Os, 2 x 2.5GbE, 1 x GbE, 6 x USB 3.2, 2 x CAN FD & 4 x Serials, extra 4 x 2.5GbE PoE (option)
2 x 2.5” SSD, 1 x NVMe ultra-speed SSD for data integrity
Up to 4 WWAN/WLAN combinations for mobile router applications
Up to two Hailo AI accelerator (26TOPS workload each) computing power in option
9~36V DC-IN with ignition control & OCP/OVP
Wide range operating temperature of -40°C~70°C (fanless@35W CPU)
Military standard for anti-vibration/shock
CE/FCC, UKCA, Emark Certified

View Product

MSM362M & MSM362I mSATA mini SSD

16/32/64/128GB mSATA mini SSD

Key Features:

Compliant with RoHS 2.0 standards
Compliant with JEDEC MO-300B
MLC NAND flash
Supports Transcend Scope Pro software
Promised operational reliability in a wide temperature range (from -40° to 85°C)
Built-in BCH ECC (Error Correction Code) functionality
Advanced Global Wear-Leveling and Block management for reliability
Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
TRIM command for better performance

View Product

VTC7260-x Fanless AI-Aided Vehicle Computer

Fanless AI-aided Vehicle Computer with Intel Core 11th Gen CPU

Key Features:

Intel 11th Gen Tiger Lake UP3, cost-efficient performance
Compact, rugged and fanless design
Rich I/Os, 2 x 2.5GbE, GbE, 4 x USB 3.2/2.0 & 3 x RS232/422/485
1 x 2.5” SSD, 1 x mSATA and 1 x NVMe SSD for data integrity
Up to 3 combinations of LTE/5G, and Wi-Fi 5/6 for mobile router function
Triple display, VGA, HDMI and DP for multi video-out
9~36V DC-IN with ignition control & OCP/OVP
Wide range operating temperature of -30°C~65°C (15W TDP)
Military standard of anti-vibration/shock for OHV applications
CE/FCC, UKCA, Emark Certified

View Product

ATC3750-6C NVIDIA Jetson AGX Orin Edge AI Computer

NVIDIA Jetson AGX Orin Solution Performance Edge AI Computing for Rail

Key Features:

Built-in NVIDIA Jetson AGX Orin SOM, up to 200/275 TOPS (INT8) performance
Designed with rugged, compact and the hybrid thermal solutions
6-port GbE PoE+ (x-coded) for IP CAM/LiDAR sensors, optional 1-port 10GbE (x-coded)
HEVC/H.265 hardware DECODE@ 6 x 4K30 performance
Wide range operating temperature of -30°C~70°C
Ultra-speed PCIe 4.0 x4 NVMe SSD for data integrity
Expansible for GNSS, LTE/5G NR & Wi-Fi 5/6
24V DC-IN for rail, ignition control & OCP/OVP
NEXCOM Acceleration Linux (NAL) integrated w/ JetPack 5.0.2
Military standard of MIL-STD-810H for anti-vibration/shock
CE/FCC, UKCA, EN50155 (EN55011, EN50121-3-2, EN61373, OT4) Certified

View Product

RM520N-GL 5G Sub-6 GHz M.2 Module

5G Sub-6 GHz M.2 Module optimized specially for IoT/eMBB applications

Key Features:

5G/4G/3G multi-mode module with M.2 form factor, optimized for IoT and eMBB applications
Worldwide 5G and LTE-A coverage
Both NSA and SA modes supported
Multi-constellation GNSS receiver available for applications requiring fast and accurate fixes in any environment
Feature refinements: DFOTA and VoLTE (optional)

View Product

EM120K-GL LTE-A Cat 12 M.2 Module

LTE-A Cat 12 M.2 Module 600Mbps/150Mbps

Key Features:

LTE-A Cat 12 module with M.2 form factor
Support DL 3 Carrier Aggregation and 256QAM
Worldwide LTE-A and UMTS/ HSPA+ coverage
Built-in eSIM (optional), DSSA
Low power mode
Multi-constellation GNSS receiver available for applications requiring fast and accurate fixes in any environment
MIMO technology meets demands for data rate and link reliability in modem wireless communication systems
