CMC 300-F0x Cabinet Mount Fanless PC

In stock
SKU:
CMC300-F0x
Brand: Nexcom

Cabinet Mount Fanless PC with Intel® Xeon® E-2278GEL and 8th & 9th Gen Intel® Core™ i7/i5/i3 Processors



Enquire Now
Enquire about this product:

CMC 300-F0x is an Industrial Fanless PC designed with the purpose of being installed in the plate of the control cabinet or in the rear plate of a control cabinet. The Fanless PC cut-in to a suitable cut-out in the control cabinet and its heatsink is at outside the cabinet with IP65 protection. The CMC 300-F0x supports up to high performance Intel Xeon grade CPU with two external 2.5” HDD trays. Designed for easy maintenance condition in the industrial applications such as wind power, charging station, etc.

  • Fanless system design with slim type
  • Intel® Xeon® E-2278GEL and 8th & 9th Gen Intel® Core™ i7/i5/i3 LGA socket type processors
  • 2 x Gigabit Ethernet
  • 2 x USB 2.0, 2 x USB 3.0, 1 x COM RS232/422/485
  • IP65 protection on the outside heatsink
  • 1 x DVI-D display output
  • 2 x DDR4 up to 64GB
  • 1 x mini-PCIe for storage device
  • 2 x Easy-access 2.5” SSD trays
  • Support power input 24 VDC

This product is listed in Industrial Computing, Embedded Computers, Industrial Automation, Mining
CPU Support Support Intel® Xeon® E-2278GELSupport 8th & 9th Gen Intel® Core™ i7/i5/i3 LGA socket type:
- Intel® Core™ i3-8100T, i5-8500T, i7-8700T
- Intel® Core™ i3-9100TE, i5-9500TE, i7-9700TE
Support up to 35W CPU
PCH Intel® C246 PCH
Main Memory 2 x DDR4 2400/2666 SO-DIMM sockets, support up to 64GB with non-ECC and un-buffered
I/O Interface Status LEDs PowerSATA (SSD)
I/O Interfac DC power input connector: 3-pin Phoenix Contact terminal blocksCOM: 1 x RS232/422/485Display: 1 x DVI-D portEthernet: 2 x RJ45
- LAN: 1 x Intel® I219-LM PHY LAN and 1 x Intel® I210-IT Gigabit LAN
- Ethernet interface: 10/100/1000 Mbps
- Support wake up on LAN
2 x USB 2.0 ports2 x USB 3.0 ports2-pin remote power on/off1 x Easy-access RTC battery socket
Storage Device 2 x Easy-access 2.5” SSD trays1 x mini-PCIe slot for storage
Power Requirements DC power input:
- Input voltage: 18VDC -5% to 24VDC +10%, 7.5A
- Reverse polarity protection
Environment Operating temperature:
- 0°C to 55°C with natural convection
- 0°C to 60°C with mild forced airflow
Operating humidity support 10%~90% relative humidity,non-condensingVibration protection w/ HDD condition:
- Random: 0.5Grms @ 5~500 Hz, IEC60068-2-64
- Sinusoidal: 0.5Grms @ 5~500 Hz, IEC60068-2-64
Dimensions Dimension: 330mm x 275mm x 116.2mmWeight: 5.7 KG
Construction Aluminum extrusion heat sink and iron nickel plating housingBack cover with reserved RAID card heatsink holeIP65 protection for the outside heatsink
Certifications CE (EN61000-6-2/EN61000-6-4)FCC Class A
OS Support List Windows 10 64-bit
