55BDL2105X 55" FHD 24/7 Tiled Display
55BDL2105X 55" FHD 24/7 500cd/m² Slim-Bezel
Key Features:
- Effortless setup. Total control.
- Operate, monitor and maintain with CMND & Control
- Add Android processing power with an optional CRD50 module
- Cost-effective system solution
- FailOver ensures content is always playing
- Brilliant images. Endless possibilities.
- Full HD monitors. Brilliant images. Clear contrast
- IPS panel: rich color consistency from every angle
- Ultra-narrow bezels. For distraction-free images
- Powerful system solution
- Energy-saving automatic backlight control
- OPS slot allows for PC embedding without cabling
- Tiling mode. Create tiled 4K videowalls of any size
The 55BDL2105X is a 55 inch 24/7 video wall display with slim bezels to enable a clearer image. Failover ensures an output is always displayed even in the event of the primary source disconnecting. Also equipped with CMND & Control for network management alongside tiling mode for a videowall expreience without the need for external players.
Key Features:
- Effortless setup. Total control.
- Operate, monitor and maintain with CMND & Control
- Add Android processing power with an optional CRD50 module
- Cost-effective system solution
- FailOver ensures content is always playing
- Brilliant images. Endless possibilities.
- Full HD monitors. Brilliant images. Clear contrast
- IPS panel: rich color consistency from every angle
- Ultra-narrow bezels. For distraction-free images
- Powerful system solution
- Energy-saving automatic backlight control
- OPS slot allows for PC embedding without cabling
- Tiling mode. Create tiled 4K videowalls of any size
Picture/Display
• Diagonal screen size: 54.5 inch / 138.7 cm
• Panel resolution: 1920x1080p
• Optimum resolution: 1920 x 1080 @ 60 Hz
• Brightness: 500 cd/m²
• Dynamic contrast ratio: 500,000:1
• Response time (typical): 8 ms
• Aspect ratio: 16:9
• Viewing angle (H / V): 178 / 178 degree
• Pixel pitch: 0.63 x 0.63 mm
• Display colors: 16.7 M
• Contrast ratio (typical): 1200:1
• Haze: 25 %
Supported Display Resolution
• Computer formats
640 x 480 60, 72, 75Hz
720 x 400 70Hz
800 x 600 60, 75Hz
1024 x 768 60, 75Hz
1280 x 768 60Hz
1280 x 800 60Hz
1280 x 960 60Hz
1280 x 1024 60Hz
1360 x 768 60Hz
1366 x 768 60Hz
1600 x 1200 60Hz
1920 x 1080 60Hz
• Video formats
720p 50, 60Hz
1080i 25, 30Hz
1080p 50, 60Hz
2160P 50 60Hz ((HDMI/OPS/DP)
Connectivity
• Video input: Display Port1.2 (x1), DVI-D (x1),
HDMI 2.0 (x2), VGA (Analog D-Sub) (x1)
• Audio input: 3.5 mm mini jack (x1)
• Video output: DisplayPort 1.2 (x1)
• Audio output: 3.5 mm Mini Jack (x1)
• External control: IR (in) 3.5 mm jack, LAN RJ45
(x2)
• Other connections: OPS, USB 2.0 (x1), Thermal
sensor
Convenience
• Placement: Landscape (24/7), Portrait (24/7)
• Tiled Matrix: Up to 15 x 15
• Screen saving functions: Pixel Shift, Low Bright
• Signal loop through: DisplayPort, RJ45
• Ease of installation: Carrying Handles, Smart Insert
• Energy saving functions: Smart Power
• Network controllable: LAN (RJ45)
Operating conditions
• Temperature range (operation): 0 ~ 40 °C
• Temperature range (storage): -20 ~ 60 °C
• Altitude: 0 ~ 3000 m
• MTBF: 50,000 hour(s)
• Humidity range (operation)[RH]: 20 - 80%
(without condensation)
• Humidity range (storage) [RH]: 5 - 95% (without
condensation)
Power
• Consumption (Typical): 180 W
• Consumption (Max): 340 W
• Consumption (On mode): 140 W
• Standby power consumption: 0.5 W
• Energy Label Class: G
Sound
• Built-in speakers: 2 x 10W (RMS)
Accessories
• Included Accessories: Gap pad x3, IR sensor cable
(1.8 m) (x1), Kit-1 (x1), Kit-2 (x2), Quick start
guide (x1), Remote control & AAA batteries, RJ45
/ RS232 converter, Wire Clamper (x3), Power
cord, DP cable (x1), Edge alignment pin (x2), RJ45
cable (x1)
Miscellaneous
• On-Screen Display Languages: Arabic, English,
French, German, Italian, Japanese, Polish, Russian,
Spanish, Simplified Chinese, Turkish, Traditional
Chinese
• Regulatory approvals: CE, FCC, Class A, RoHS,
CB, BSMI, ETL
• Warranty: 3 years warranty
Dimensions
• Smart Insert mount: 100mm x 100mm, 6xM4xL6
• Set dimensions (W x H x D):
1213.5 x 684.3 x 97.8 mm(D@WallMount)/97.8
mm(D@Handle) mm
• Set dimensions in inch (W x H x D):
47.77 x 26.94 x 3.85 (D@WallMount)/3.85
(D@Handle) inch
• Bezel width: 2.3 mm + 1.2 mm
• Wall Mount: 400mm x 400mm, M6
• Product weight: 28.8 kg
